Description
Reproduce True-to-Life Images for Totally Immersive and Interactive Experiences
- 0.72-0.87 flexible short throw ratio for large image from short distant.
- Flexible installation with Screen Fill, 2D Keystone, and Corner Fit.
- Effortless and consistently blending experience with BenQ unique white balance adjustment.
- Wi-Fi ready with an optional dongle for wireless projection from mobile device.
All Specifications
Display
Brightness (ANSI lumens)3200
ResolutionWXGA (1280×800)
Native Aspect Ratio16:10
Contrast Ratio (FOFO)20,000:1
Display Color30-bit (1.07 billion colors)
Light Source4LED
Light Source Lifea. Normal 20000 hrs, b. ECO 30000 hrs
Optical
Throw Ratio0.72-0.87
Zoom Ratio1.2x
Projection Offset (Full-Height)100%
Keystone Adjustment2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees
Rec. 709 Coverage94%
Picture Modes3D, Bright, Presentation, Simulator, sRGB, User 1, User 2, Vivid
Compatibility
Input Lag33.4 ms (1080P 60Hz)
Resolution SupportVGA(640 x 480) to Full HD(1920 x 1080)
Horizontal Frequency15K~102KHz
Vertical Scan Rate23~120Hz
I/O Interface
HDMI inHDMI-1 (1.4a/HDCP1.2), HDMI-2 (1.4b/HDCP1.4)
USB Type AUSB Type A(2.0/Reader/FW Upgrade), USB Type A-1 (2.0/Power Supply1.5A)
RS232 in (DB-9pin)(x1)
Audio
Speaker 10W
Audio out (3.5mm Mini Jack)(x1)
Environment
Operating Temperature0~40℃
Power SupplyAC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V)215W
Stand-by Power Consumption<0.5W
Acoustic Noise (Typ./Eco.)(dB)34dBA/28dBA
Accessories
Wireless USB dongleEZC-5201BS 1080p, (Optional)
Remote Control w/ BatteryRCX016
Power Cord (by region)x1 (1.8M)
3D GlassesDGD5
Quick Start Guide(x1) 21L
Warranty Card (by region)Yes
Lens coverYes
Smart System
Wi-Fi Standard802.11 a/b/g/n/ac (2.4G/5G)
Dimension & Weight
Dimensions (WxHxD) (mm)303.5*107.4.*220.7
Net Weight (kg)2.65
Net Weight (lb)5.84
Projection System
Projection SystemDLP
